   Appearance-based object recognition methods have recently demonstrated good
  performance on a variety of problems.
  However, many of these methods either require good whole-object segmentation,
  which severely limits their performance in the presence of clutter,
  occlusion, or background changes; or utilize simple conjunctions of
  low-level features, which causes crosstalk problems as the number of
  objects is increased.
  We are investigating an appearance-based object recognition system
  using a keyed, multi-level context representation, that
  ameliorates many of these problems, and can be used with complex,
  curved shapes.
  Pictures on this page are from a training database we have used in
  system tests.

  Appearance-based object recognition methods have recently demonstrated good
  performance on a variety of problems.
  However, many of these methods either require good whole-object segmentation,
  which severely limits their performance in the presence of clutter,
  occlusion, or background changes; or utilize simple conjunctions of
  low-level features, which causes crosstalk problems as the number of
  objects is increased.
  We are investigating an appearance-based object recognition system
  using a keyed, multi-level context representation, that
  ameliorates many of these problems, and can be used with complex,
  curved shapes.
  Pictures on this page are from a training database we have used in
  system tests.


  Specifically, we utilize distinctive intermediate-level features
  in this case automatically extracted 2-D boundary fragments,
  as keys, which are then verified within a local context, and
  assembled within a loose global context to evoke an overall percept.
  The system demonstrates extraordinarily good recognition of a variety of
  3-D shapes, ranging from sports cars and fighter planes to snakes and
  lizards with full orthographic invariance.
  We have performed a number of large-scale experiments,
  involving over 2000 separate test images, that evaluate performance with
  increasing number of items in the database, in the presence of clutter,
  background change, and occlusion, and also the results of some
  generic classification experiments where the system is tested on
  objects never previously seen or modeled.
  To our knowledge, the results we report are the best in the literature
  for full-sphere tests of general shapes with occlusion and clutter
  resistance.




   The basic idea is to represent the visual appearance of an object as
  a loosely structured combination of a number of local context regions
  keyed by distinctive key features, or fragments.
  A local context region can be thought of as an image
  patch surrounding the key feature  and containing a representation of
  other features that intersect the patch.
  Now under different conditions (e.g. lighting, background,
  changes in orientation etc.) the feature extraction process will
  find some of these distinctive keys, but in general not all of them.
  Also, even with local contextual verification, such keys may well be
  consistent with a number of global hypotheses.
  However, the fraction that can be found by existing feature extraction
  processes is frequently sufficient to identify objects in the scene,
  once the global evidence is assembled.
  This addresses one of the principle problems of object recognition,
  which is that, in any but rather artificial conditions, it has so far proved
  impossible to reliably segment whole objects on a bottom-up basis.
  In the current system, local features based on automatically extracted
  boundary fragments are used to represent multiple
  2-D views (aspects) of rigid 3-D objects, but the basic idea could be
  applied to other features and other representations.

  The basic idea is to represent the visual appearance of an object as
  a loosely structured combination of a number of local context regions
  keyed by distinctive key features, or fragments.
  A local context region can be thought of as an image
  patch surrounding the key feature  and containing a representation of
  other features that intersect the patch.
  Now under different conditions (e.g. lighting, background,
  changes in orientation etc.) the feature extraction process will
  find some of these distinctive keys, but in general not all of them.
  Also, even with local contextual verification, such keys may well be
  consistent with a number of global hypotheses.
  However, the fraction that can be found by existing feature extraction
  processes is frequently sufficient to identify objects in the scene,
  once the global evidence is assembled.
  This addresses one of the principle problems of object recognition,
  which is that, in any but rather artificial conditions, it has so far proved
  impossible to reliably segment whole objects on a bottom-up basis.
  In the current system, local features based on automatically extracted
  boundary fragments are used to represent multiple
  2-D views (aspects) of rigid 3-D objects, but the basic idea could be
  applied to other features and other representations.




   The basic recognition strategy is to utilize a database
  (here viewed as an associative memory)
  of key features embedded in local contexts, which is organized
  so that access via an unknown key feature evokes associated hypotheses for the
  identity and configuration of all known objects that
  could have produced such an embedded feature.
  These hypotheses are fed into a second stage associative memory,
  keyed by configurations,
  which lumps the hypotheses into clusters that are mutually consistent
  within a loose global context.
  This secondary database maintains a probabilistic estimate of the likelihood of
  each cluster based on statistics about the occurrence of the keys
  in the primary database.
  The idea is similar to a multi-dimensional Hough transform without
  the space problems.
  In our case, since 3-D objects are represented by a set of
  views, the configurations represent two dimensional transforms of
  specific views.
  Efficient access to the associative memories is achieved using a hashing
  scheme on parameters of the keying features, followed by verification
  of the local context.
  As mentioned above, this local verification step gives the voting features
  sufficient power to substantially ameliorate well known problems with
  false positives in Hough-like voting schemes.
  Details on associative memory
  The basic recognition strategy is to utilize a database
  (here viewed as an associative memory)
  of key features embedded in local contexts, which is organized
  so that access via an unknown key feature evokes associated hypotheses for the
  identity and configuration of all known objects that
  could have produced such an embedded feature.
  These hypotheses are fed into a second stage associative memory,
  keyed by configurations,
  which lumps the hypotheses into clusters that are mutually consistent
  within a loose global context.
  This secondary database maintains a probabilistic estimate of the likelihood of
  each cluster based on statistics about the occurrence of the keys
  in the primary database.
  The idea is similar to a multi-dimensional Hough transform without
  the space problems.
  In our case, since 3-D objects are represented by a set of
  views, the configurations represent two dimensional transforms of
  specific views.
  Efficient access to the associative memories is achieved using a hashing
  scheme on parameters of the keying features, followed by verification
  of the local context.
  As mentioned above, this local verification step gives the voting features
  sufficient power to substantially ameliorate well known problems with
  false positives in Hough-like voting schemes.
  Details on associative memory


  A fundamental component of the approach is the
  use of distinctive local features we call keys.
  A key is any robustly extractable part or feature that has
  sufficient information content to specify a configuration
  of an associated object plus enough additional, pose-insensitive
  (sometimes called semi-invariant)
  parameters to provide efficient indexing.
  The local context amplifies the power of the feature
  by providing a means of verification.
  This local verification step is critical, because the invariant parameters
  of the key features are relatively weak evidence, leading to a proliferation
  of high-scoring false hypotheses if used alone.
  This is a well known problem with voting schemes, but can be alleviated
  if the voting features are sufficiently powerful.
  In the current implementation we have utilized keys based on
  extracted boundary fragments, both straight and curved, but the
  method is by no means limited to such keys, and we are looking at several
  complementary feature types.
  Details on keys used.




   In order to use the system with an object, its appearances must be stored
  in the associative memory.
  Currently, this is done by obtaining a number of uncluttered images of the
  object from different directions. About 100 views are needed to cover the
  entire viewing sphere for the curve-based keys we have used.
  For each view, key features are extracted, and a number of the strongest
  are stored in the memory with associated information about the object
  and view that produced them, and their relationship to an arbitrarily
  specified 2-D configuration (position, orientation, scale) for that
  view.
  In order to use the system with an object, its appearances must be stored
  in the associative memory.
  Currently, this is done by obtaining a number of uncluttered images of the
  object from different directions. About 100 views are needed to cover the
  entire viewing sphere for the curve-based keys we have used.
  For each view, key features are extracted, and a number of the strongest
  are stored in the memory with associated information about the object
  and view that produced them, and their relationship to an arbitrarily
  specified 2-D configuration (position, orientation, scale) for that
  view.


  To recognize an object, that is to answer the question "what object
  is in this image?", key features together with their local contexts
  are extracted from the image, and
  fed into the associative memory.
  All matches are retrieved,
  and for each match, the associated information is used to compute
  a hypothesis about the identity, view, and configuration of a possible
  object.
  This hypothesis is fed to a second, "working" associative memory, where
  current hypotheses are stored. If any matches are found, the
  evidence associated with them is updated to reflect the new
  information.
  Otherwise a new hypothesis is entered.
  The accumulation is not a flat voting process, but depends on
  the frequency of occurrence of the feature over the entire database,
  with uncommen features providing more evidence.
  The evidence combination scheme is Bayesian if the features are independent
  (they are not, but we don't have a better model, and the results are better
  than flat voting).
  The hypothesis memory is them examined, and the configuration
  with the most evidence selected as the most probable answer.




   To find an object of known characteristics in a scene, that
  is to answer the question of the form "where is the dog in this image?",
  the same procedure is followed, except that key feature matches
  are filtered on the basis of whether the came from a view of a dog.
  This actually provides a rather powerful mechanisms for partially
  indexed retrieval, since the filtering can occur on any combination
  of attributes that we care to associate with the features, either in
  the database, or from the image, e.g. "animal", or "pink cup".
  Details of algorithm.
  To find an object of known characteristics in a scene, that
  is to answer the question of the form "where is the dog in this image?",
  the same procedure is followed, except that key feature matches
  are filtered on the basis of whether the came from a view of a dog.
  This actually provides a rather powerful mechanisms for partially
  indexed retrieval, since the filtering can occur on any combination
  of attributes that we care to associate with the features, either in
  the database, or from the image, e.g. "animal", or "pink cup".
  Details of algorithm.


  The approach has several advantages.
  First, because it is based on a merged percept of local features rather than
  global properties, the method is robust to occlusion and background
  clutter, and does not require prior segmentation.
  This is an advantage over systems based on principal components
  template analysis, which are sensitive to occlusion and clutter.
  Second, entry of objects into the memory is an active, automatic procedure.
  Essentially, the system explores the object visually from different
  viewpoints, accumulating 2-D views,  until it has seen enough not to mix
  it up with any other object it knows about.
  Third, the method lends itself naturally to multi-modal recognition.
  Because there is no single, global structure for the model, evidence from
  different kinds of keys can be combined as easily as evidence from
  multiple keys of the same type.
  The only requirement is that the configuration descriptions
  evoked by the different keys have enough common structure to
  allow evidence combination procedures to be used.
  This is an advantage over conventional alignment techniques, which
  typically require a prior 3-D model of the object.
  Finally, the probabilistic nature of the evidence combination scheme,
  coupled with the formal definitions for semi-invariance and robustness
  allow quantitative predictions of the reliability of the system to be made.




   We have run several large-scale performance tests,
  involving, altogether, over 2000 separate test images.
  In these experiments we investigate variation in performance with respect
  to increasing database size, clutter, and occlusion.
  In forced choice experiments using clean test images from a 24 object
  database, we obtain 97% classification accuracy.
  Performance with 75% clutter and 25% occlusion is in the 90%+ range.
  We have developed a statistical model for predicting the performance
  in a variety of situations from a few basic measurements of score
  distributions for clean test images and pure clutter.
  We also ran a generic recognition experiment, where the
  system was trained on several
  objects in each of several several classes, (e.g. planes, snakes, cars),
  and asked to classify example objects from the same generic classes, but
  not in the training set.
  Details of experiments.
  We have run several large-scale performance tests,
  involving, altogether, over 2000 separate test images.
  In these experiments we investigate variation in performance with respect
  to increasing database size, clutter, and occlusion.
  In forced choice experiments using clean test images from a 24 object
  database, we obtain 97% classification accuracy.
  Performance with 75% clutter and 25% occlusion is in the 90%+ range.
  We have developed a statistical model for predicting the performance
  in a variety of situations from a few basic measurements of score
  distributions for clean test images and pure clutter.
  We also ran a generic recognition experiment, where the
  system was trained on several
  objects in each of several several classes, (e.g. planes, snakes, cars),
  and asked to classify example objects from the same generic classes, but
  not in the training set.
  Details of experiments.




Andrea Selinger and Randal C. Nelson, ``A Perceptual Grouping Hierarchy for Appearance-Based 3D Object Recognition'', Computer Vision and Image Understanding, vol. 76, no. 1, October 1999, pp.83-92. Abstract, gzipped postscript (preprint)
Randal C. Nelson and Andrea Selinger ``Large-Scale Tests of a Keyed, Appearance-Based 3-D Object Recognition System'', Vision Research, Special issue on computational vision, Vol. 38, No. 15-16, Aug. 1998. Abstract, gzipped postscript (preprint)
Randal C. Nelson and Andrea Selinger ``A Cubist Approach to Object Recognition'', International Conference on Computer Vision (ICCV98), Bombay, India, January 1998, 614-621. Abstract, gzipped postscript, also in an extended version with more complete description of the algorithms, and additional experiments.
Randal C. Nelson, Visual Learning and the Development of Intelligence, In Early Visual Learning, Shree K. Nayar and Tomaso Poggio, Editors, Oxford University Press, 1996, 215-236. Abstract,
Randal C. Nelson, ``From Visual Homing to Object Recognition'' , in Visual Navigation, Yiannis Aloimonos, Editor, Lawrence Earlbaum Inc, 1996, 218-250. Abstract,
Randal C. Nelson, ``Memory-Based Recognition for 3-D Objects'', Proc. ARPA Image Understanding Workshop, Palm Springs CA, February 1996, 1305-1310. Abstract, gzipped postscript
Randal C. Nelson, ``3-D Recognition Via 2-stage Associative Memory'', University of Rochester, Dept of Computer Science TR 565, January 1995. Abstract, gzipped postscript
